Series 116 Stainless Steel, 150 MPa
A CEJN original design for use on traditional tools such as tensioners, wrenches, pullers, power packs and more in harsh and corrosive environments. It features extremely small outside dimensions, and non-drip functionality is a given feature. All exposed components are stainless steel, or even acid proof steel, to provide the longest possible service life and thus save both the environment and money. To further extending service life of the entire hydraulic system both coupling and nipple are provided with plastic dust caps. Aluminum dust caps can be ordered separately.
| Adapters | Part No. | Remark | Connection | Length | Diameter | Hexagon | Rec. torque (Nm) | Rec. seal. method |
| Male to male | 19 950 1711 | G 1/4" CMS* to G 1/4" CMS* | - | - | - | 17 | - | - |
| Technical data | |
| Nominal flow diameter: | 2.5 mm (3/32") |
| Flow capacity: | 6.0 l/min (1.3 GPM UK) |
| Max. working pressure: | 150.0 MPa |
| Min. burst pressure: | 300.0 MPa |
| Temperature range: | -30°C — +100°C (-22°F — +212°F) |
| Material coupling: | AISI 316, Hardened stainless steel |
| Material nipple: | AISI 316, Hardened stainless steel |
| Material seal: | Nitrile (NBR) other sealing materials on request |
Flow capacity is measured at 0.4 MPa pressure drop.
Oil Flow
Pressure drop, MPa
Flow, l/min. (GPM UK)
***Please Note: Item Photos above are for General Reference and may not always be exact. Please see the product description and quick overview section for complete listing of item details and any additional components and specifications***
| UPC | 029292918566 |
|---|---|
| Item Type | Accessories / Tools |
| Product Availability | Ships in 24-48 Hours, FOB: Point of Origin |
| Manufacturer | CEJN |
