40-5000W040 SC Hydraulic Power Unit, Aluminum/Bronze, 10-5 Series Pump, 70:1 Ratio

Part #40-5000W040 SC Hydraulic Power Unit, Aluminum/Bronze, 10-5 Series Pump, 70:1 Ratio
Special Price $3,707.85 was $3,903.00
SKU
40-5000W040
40-5000W040 SC Hydraulic Power Unit, Aluminum/Bronze, 10-5 Series Pump, 70:1 Ratio is available to buy in increments of 1

SC Hydraulic Power Unit, Aluminum/Bronze, 10-5 Series Pump, 70:1 Ratio

The 40 Series incorporates a larger base plate than the 30 Series to accommodate an optional two or three gallon reservoir. Two pressure ports, one equipped with shut-off or bleed valve, provide ease of control during operation. Valve connects to reservoir when so equipped.

  • Light weight
  • easy to install

Only three connections are required; air, fluid supply, and work port.

Application:

  • Staking
  • Piercing
  • Pressing
  • Blanking
  • Clamping
  • Flow testing
  • Metal forming
  • Static and burst testing
  • Hydraulic press operation
Model No.
Standard
10 Series Hydraulic
Section Code
Pump Ratio Gauge Pressure Overall Dimensions (in) Ports NPT
W D H Air Drive Fluid Supply Pressure
40-5 Series 040 70:1 0-10,000 28.00 12.50 13.50 1/2" 1/2" 3/8"





***Please Note: Item Photos above are for General Reference and may not always be exact. Please see the product description and quick overview section for complete listing of item details and any additional components and specifications***

More Information
Manufacturer SC Hydraulic
Product Availability Intermittent stocking item, call for specific ship date. Please note, we go into production on some items as soon as we receive your order. It is highly recommended that you place your order as soon as possible.
SC Hydraulic Power Unit Series 40 Series
Pump Construction (W) Aluminum Bronze & Stainless Steel (Standard)
SC Hydraulic Power Unit Gauge Range 0 - 10,000 psi
SC Hydraulic Power Unit Oil Port Outlet Size 3/8" NPT
SC Hydraulic Power Unit Oil Port Inlet Size 1/2" NPT
SC Hydraulic Power Unit Air Drive Port Size 1/2" NPT
